Key specifications
Coolant flow up to
400
l / min
Cooling power up to
162
kW
Cabinet footprint
400 x 600
mm
Certifications
Adwatec has a DNV type approval certificate
for C-series liquid cooling stations.
Benefits
- High-performance cooling in an ultra-compact footprint
- Stable closed-loop cooling system isolating and protecting sensitive power electronics
- Factory-tested, pre-engineered models ensure consistent and reliable operation
- Easy and fast integration with cooling circuits
- Low maintenance requirements
- DNV type approval streamlines system certification and documentation documentation
Key features
- Cooling capacity up to 162 kW
- Coolant flow up to 400 l/min
- Active coolant temperature control available
- Extra narrow design, fits inside a 400 x 600 mm cabinet
- Automatic de-aeration and visual coolant level indication for fast commissioning
- Cooling liquid level monitoring for tracking possible leakages
- Sensors and meters centralized to the front-side of the unit for easy access
- High-quality components and materials, including stainless steel industrial pumps
- Manifold structure for less connection points and smaller footprint
- Selection of standard connection pipes
Design your
own solution
Adwatec water cooling solution configurator is the first online application that allows you to design your water cooling station easily whenever, wherever.
Adwatec Academy
Our training and support resources about water cooling.
Power electronics generate heat. This heat is not good for the electrical components in power electronics system and therefore
it needs to be removed from the system.
Water cooling stands out as a superior thermal management solution due to its exceptional energy efficiency and resulting
energy savings, coupled with a compact footprint and near-silent operation; its inherent safety makes it ideal for critical applications like battery cooling, while its robust design ensures reliability in
harsh condition applications, and ultimately, it boasts leading performance in terms of installation and maintenance costs.
